The selection of Rolling mill Bearing

As one of the most professional rolling mill bearing manufacturers and suppliers in China, DAC Bearing featured by high quality bearings with different specifications and sizes.DAC’s tips for selecting a roller mill bearing.



http://www.dacbearing.com/products/Rolling-Mill-Bearing/NNU-Series/480.html

1.Selection based on the working conditions

a.Working temperature

Chromium steel  is suit for working at room temperature . When the working temperature is higher than 150 ° C and lower than 250 ° C, chromium bearing steel is also workable , but special heat treatment is required (tempering at 200 ° C or 300 ° C is required).

b. Load Capacity

Don’t use chromium bearing steel in strong impact load generally , the high-quality carburized structural steel, impact-resistant tool steel or quenched and tempered structural steel are strongly recommended.

c. Contact medium

Bearings used in corrosive media must be made of corrosion-resistant steel or alloy steel with good corrosion resistance.


2.Selection based on the type of the bearing structure

The structure of the bearing parts is complicated.  when the one with outer ring is equipped with ribs and bears works under a high impact load condition, carburized steel with good processing performance should be used;if the stamping needle roller bearing, the outer ring  choose 08 and 10 low carbon steel,


3. Selection based on bearing fatigue life and reliability requirements

In  a certain extent,Bearing fatigue life and reliability depend on the purity and uniformity of the steel. For general use occasions, ordinary bearing steel smelted in acidic open furnace or alkaline electric furnace is used. With the continuous improvement of smelting methods,some new smelting methods such as current remelting, vacuum smelting, and electron beam furnace smelting have been produced,in which has increased the bearing life accordinly and suitable for bearings with special requirements for fatigue life and reliability.


Furthermore, take  steel's processing performance, supply of goods and domestic resources into  consideration comprehensively in selection.


Note: The applicable range of three common high-carbon chromium bearing steels is as follows:

Media Number

Range of Application  (mm)

Ferrule

Steel ball

Roller ball

GCR 15

Effective thick 12

Diameter30

Diameter22

GCr15SiMn

Effective thick 12

Diameter30

Diameter22

GCr18Mo

Effective thick 12

Diameter80

Diameter50
